200HR-150 Manual Rockwell Hardness Tester
Manual simple Rockwell Hardness tester
Features:
l The machine body adopts cast iron structure, which is strong and durable, thus it can be used in various harsh conditions.
l Lever loading, manual operation; no need for electric controlling
l Frictionless loading shaft, high precision testing force
l Precision conforms to the Standards of GB/T 230.2, ISO 6508-2 and ASTM E18
Applications:
It can be used to test the Rockwell hardness of hard alloy, carburized steel, hardened steel, surface quenched steel, hard cast steel, aluminum alloy, copper alloy, malleable cast, mild steel, tempered steel, annealed steel, bearing steel, etc.
Technical Parameter:
Measuring Range: 20-88HRA ,20-100HRB,20-70HRC
Initial Test Force: 10Kgf(98.07N)
Total Test Force: 60Kgf(558.4N),100Kgf(980.7N),150Kgf(1471N)
Hardness Value Reading: Dial gauge
Carriage control: Manual loading/unloading
Max. height of test piece: 210mm
Depth of throat: 160mm
Min. scale value: 0.5HR
Dimension: 510*220*700mm
Package dimension:620*490*780 mm
Weight: 85Kg/100Kg
Standard delivery:
Main unit 1 |
Rockwell standard blocks: 5 |
Large flat anvil 1 |
Screw driver 1 |
Small flat anvil 1 |
Auxiliary box 1 |
V-notch anvil 1 |
Dust cover 1 |
Diamond cone penetrator 1 |
Operation manual 1 |
Steel ball penetrator φ1.588mm 1 |
Certificate 1 |
Steel ball φ1.588mm: 5 |
|
